LED Strip Lamp with Aluminum Housing

Inquiry Form

Description
The SL2010 series small aluminum light bars are ideal for interior or exterior lighting applications. The PC light diffusion lens provides an outstandingly smooth and even light output, and the aluminum housing ensures the heat dissipation and service life. The aluminum surface on the aluminum LED light is either a natural oxide or black oxide.

They aluminum housing LED light bar also comes with a frosted lens that also provides a smooth and even output.

Features:
1. surface mount installation
2. over voltage protection
3. The aluminum extrusion housing design allows heat to easily dissipate, and ensures a long service life.
4. Colors are available in black or aluminum oxidation color.
5. Aluminum color oxidation finish

Part No LED Light source power Luminous Flux Length Comments
SL2010-50 30pcs 5W 500 lm L=500mm
SL2010-750 45pcs 7.5W 750 lm L=750mm
SL2010-100 60pcs 10W 1000lm L=1000mm
SL2010-50-S 30pcs 6W max 500 lm L=500mm With a switch
SL2010-750-S 45pcs 9W max 750 lm L=750mm
SL2010-100-S 60pcs 12W max 1000lm L=1000mm
SL2010-50-IR 30pcs 6W max 500 lm L=500mm With an infrared sensor
SL2010-750-IR 45pcs 9W max 750 lm L=750mm
SL2010-100-IR 60pcs 12W max 1000lm L=1000mm

Specification:
Operating Voltage:DC12V;DC24V;10~33VDC;
Operating Temperature: -40~60℃
Light Source: 5050LEDs, CRI>80
Light Color: ~3000K warm white, 4000~4500K natural white, 6000~6500K pure white
Diffused PC lens (Frosted)
Aluminum Extrusion housing in black or aluminum color oxidation finish
Available for Silicon glue potting to get IP67, water-proof and corrosion resistant

Applications
The LED strip lamp is commonly used in cabinets, cabins, motor homes, caravans, shelters, refrigerator cars, and other special vehicles in the mining and marine industry.
