LED Headlight

Description
Using the latest patented technology, (patent number: ZL201320050551) and full compliance with ECE, SAE, and GB standards, the HL90 series head lamp has a significant advantage in the LED industry. With an extremely low (18W) power consumption, the LED headlamp has a beautiful appearance and reaches international advanced levels for energy efficiency. It is an ideal choice for an energy efficient automotive industry.

• BI-HL90
• HL90
• HL90H

BI-HL90

•
•

Inquiry Form

Specification

• Function: combination of low beam, high beam, front direction indicator, front position light, daytime running light
• Operating voltage: 10~33VDC
• Operating temperature: -40~80°C
• Photometric performance: comply with ECE R112/GB25991, SAE J1383/FMVSS108
• EMC: ECE R10 &CIS PR25
• IP67

HL90

Inquiry Form

Specification

• Function:low beam/high beam
• Operating Voltage: 10~33VDC
• Operating temperature:-40~80℃
• Light Source:LED OSRAM
• Power:18W
• Photometric performance: comply with ECE R112/GB14599 requirements
• Passed ECE R10.04 test
• Outer lens: Headlamps special PC material, anti-UV, hardened, scratch-resistant.
• Precision die-cast aluminum housing
• IP67
• E-mark approved

HL90H

Inquiry Form

Specification

• Function:low beam/high beam
• Operating Voltage: 10~33VDC
• Operating temperature:-40~80℃
• Light Source:LED OSRAM
• Power:18W
• Photometric performance: comply with ECE R112/GB14599 requirements
• Passed ECE R10.04 test
• Outer lens: Headlamps special PC material, anti-UV, hardened, scratch-resistant.
• Precision die-cast aluminum housing
• IP67
• E-mark approved
